FAG B7207-C-2RSD-T-P4S-UL FAGB7207C2RSDTP4SUL
  1. pin-int

FAG B7207-C-2RSD-T-P4S-UL FAGB7207C2RSDTP4SUL

FAG B7207-C-2RSD-T-P4S-UL B72..-C-2RSD Light Duty Spindle Bearing, 35 mm Dia Bore, 72 mm OD, 1 Rows, 17 mm W, 15 deg, 25500 N Dynamic/12600 N Static/1300 N Fatigue Load

  • Manufacturer: Schaeffler Group
  • Brand Name: FAG
  • Part Number: FAGB7207C2RSDTP4SUL
  • MPN: B7207-C-2RSD-T-P4S-UL
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Barden spindle bearings are high precision, single row, angular contact ball bearings. Their special design features including contact geometry, surface design and other properties result in a bearing design that offers high precision, excellent speed ability, high rigidity and low vibration characteristics.

FAG Spindle Bearing, Light Duty, Series: B72..-C-2RSD, 35 mm Bore, 72 mm OD, 1 Rows, 17 mm Width, 15 deg Contact Angle, Double Seal Closure, 25500 N Dynamic/12600 N Static/1300 N Fatigue Load, Phenolic Resin Cage, 20000 rpm Maximum, -30 to 100 deg C, Uncoated

Bore Diameter      :      35 mm
Cage Material      :      Phenolic Resin
Closure Type      :      Double Seal
Contact Angle      :      15 deg
Finish      :      Uncoated
Load Capacity      :      25500 N Dynamic/12600 N Static/1300 N Fatigue
Maximum Speed      :      20000 rpm
Number of Rows      :      1
Outside Diameter      :      72 mm
Series      :      B72..-C-2RSD
Temperature Rating      :      -30 to 100 deg C
Type      :      Light Duty
Width      :      17 mm
  • Standard design and steel balls
  • Textile laminated phenolic resin cage
  • Outer ring centered
  • ABEC 7 nominal tolerances, ABEC 9 running accuracies
  • Seals at both sides and greased for life
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Barden_100FF3_G_74_Catalog.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/FAG_B7207_C_2RSD_T_P4S_UL_Specification_Sheet.pdf
