FAG B7019-E-T-P4S-UL FAGB7019ETP4SUL
FAG B7019-E-T-P4S-UL B70..-E Series Light Duty Spindle Bearing, 95 mm Dia Bore, 145 mm OD, 1 Rows, 24 mm W, 25 deg, 77000 N Dynamic/52000 N Static/4850 N Fatigue Load
- Manufacturer: Schaeffler Group
- Brand Name: FAG
- Part Number: FAGB7019ETP4SUL
- MPN: B7019-E-T-P4S-UL
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Barden spindle bearings are high precision, single row, angular contact ball bearings. Their special design features including contact geometry, surface design and other properties result in a bearing design that offers high precision, excellent speed ability, high rigidity and low vibration characteristics.
FAG Spindle Bearing, Light Duty, Series: B70..-E Series, 95 mm Bore Dia, 145 mm Outside Dia, 1 Rows, 24 mm Width, 25 deg Contact, 77000 N Dynamic/52000 N Static/4850 N Fatigue, Phenolic Resin Cage, 8500 rpm Maximum
| Bore Diameter | : | 95 mm |
| Cage Material | : | Phenolic Resin |
| Contact Angle | : | 25 deg |
| Load Capacity | : | 77000 N Dynamic/52000 N Static/4850 N Fatigue |
| Maximum Speed | : | 8500 rpm |
| Number of Rows | : | 1 |
| Outside Diameter | : | 145 mm |
| Series | : | B70..-E |
| Type | : | Light Duty |
| Width | : | 24 mm |
- Standard design and steel balls
- Textile laminated phenolic resin cage
- Outer ring centered
- ABEC 7 nominal tolerances, ABEC 9 running accuracies
Catalog
