FAG 7208-B-XL-TVP-UA FAG7208BXLTVPUA
  1. pin-int

FAG 7208-B-XL-TVP-UA FAG7208BXLTVPUA

FAG 7208-B-XL-TVP-UA 72..-B Angular Contact Ball Bearing, 40 mm Dia Bore, 80 mm OD, 1 Row, 18 mm W, 40 deg, 34000 N Dynamic/23500 N Static/1580 N Fatigue Load

  • Manufacturer: Schaeffler Group
  • Brand Name: FAG
  • Part Number: FAG7208BXLTVPUA
  • Alt Part Number: 7208-B-TVP-UA
  • MPN: 7208-B-XL-TVP-UA
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Single row angular contact ball bearings are self-retaining units with solid inner and outer rings and ball and cage assemblies with polyamide, sheet metal or brass cages. The raceways of the inner and outer rings are offset from each other along the bearing axis. The bearings are available in open and sealed designs. Their angular adjustment facility is very limited.

FAG Angular Contact Ball Bearing, Series: 72..-B, 40 mm Bore Dia, 80 mm Outside Dia, 1 Row, 18 mm W, 40 deg Contact, Open Closure, 34000 N Dynamic/23500 N Static/1580 N Fatigue, Steel Bearing, Polyamide Cage, 10900 rpm Maximum, 120 deg C

Bearing Material      :      Steel
Bore Diameter      :      40 mm
Cage Material      :      Polyamide
Closure Type      :      Open
Contact Angle      :      40 deg
Load Capacity      :      34000 N Dynamic/23500 N Static/1580 N Fatigue
Maximum Speed      :      10900 rpm
Number of Rows      :      1
Outside Diameter      :      80 mm
Series      :      72..-B
Temperature Rating      :      120 deg C
Width      :      18 mm
  • Modified internal construction
  • Universal design for fitting in pairs, bearing pair has small axial internal clearance in O and X arrangement
  • Solid cage made from glass fiber reinforced polyamide
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/FAG_7208_B_L_TVP_UA_Specification_Sheet.pdf
