FAG 6310-2RSR-L038-C3 Sealed Deep Groove Ball Bearing - 50 x 110 x 27 mm

FAG 6310-2RSR-L038-C3 Deep Groove Ball Bearing, 50 x 110 x 27 mm, Double Contact Seals, C3 Clearance, Steel Cage, 68 kN Dynamic / 38.5 kN Static

  • Manufacturer: Schaeffler Group
  • Brand Name: FAG
  • Part Number: FAG6310-2RSC3
  • MPN: 6310-2RSR-L038-C3
  • UPC: 4012802648874
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Deep groove ball bearings are versatile, self-retaining bearings with solid outer rings, inner rings and ball and cage assemblies. These bearings with their simple design, high resistance and low-maintenance, are available in single-row and double-row designs, as well as sealed and unsealed. Due to the manufacturing processes used, open bearings can have turned recesses in the outer ring for seals or shields.

FAG 6310-2RSR-L038-C3 is a 63 Series single-row deep groove ball bearing for a 50 mm shaft, with 110 mm outside diameter and 27 mm width. Contact rubber seals on both sides provide an integrated barrier against contaminants while retaining lubricant, and the C3 internal-clearance specification provides more radial clearance than a normal bearing. The L038 designation identifies Mobil Polyrex EM grease. Its sheet-steel cage and deep-groove raceway support efficient radial operation while also accommodating axial load in either direction. Rated capacity is 68 kN dynamic and 38.5 kN static, with a 3,950 rpm maximum speed and -20 to 100 °C operating range. This is a useful sealed C3 option for larger electric motors, industrial gearboxes, pumps, fans and driven machinery using a 50 mm bearing seat.

Bearing Material      :      Steel
Bore Diameter      :      50 mm
Cage Material      :      Sheet Steel
Closure Type      :      Double Seal
Load Capacity      :      68000 N
Maximum Speed      :      4000 rpm Grease/3950 rpm Oil
Number of Rows      :      1
Outside Diameter      :      110 mm
Seal Material      :      Rubber
Series      :      Medium Series
Temperature Rating      :      -30 to 150 deg C
Type      :      Standard
Width      :      27 mm
Single-row 63 Series sealed deep groove ball bearing; 50 mm bore x 110 mm OD x 27 mm width; 2RSR contact lip seals on both sides help retain grease and block contamination in enclosed industrial service; C3 radial internal clearance is greater than normal; L038 Mobil Polyrex EM grease; sheet-steel cage and deep raceways support low-friction radial operation plus axial load in both directions; 68 kN dynamic / 38.5 kN static load ratings; 3,950 rpm maximum speed; -20 to 100 C operating range; heavier 63 Series design is suited to 50 mm motor shafts, gearboxes, pumps, fans, conveyors and driven machinery requiring a sealed C3 bearing.
