FAG 2311-2RS-TVH FAG2311-2RSTVH
FAG 2311-2RS-TVH Cylindrical Bore Self-Aligning Ball Bearing, 55 mm Dia Bore, 120 mm OD, 2 Rows, 43 mm W, 52000 N Load
- Manufacturer: Schaeffler Group
- Brand Name: FAG
- Part Number: FAG2311-2RSTVH
- MPN: 2311-2RS-TVH
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Self-aligning ball bearings are double row, self-retaining radial ball bearings, which are part of the group of self-aligning bearings. The outer ring has a single concave raceway for the two rows of balls. As a result, the bearings permit the compensation of static and dynamic angular misalignments (skewing between the inner and outer ring) within certain limits. The inner ring has two formed raceway grooves in which the rolling elements run.
FAG Self-Aligning Ball Bearing, Cylindrical Bore, Series: 23 Series, 55 mm Bore, 120 mm OD, 2 Rows, 43 mm Width, Sealed Closure, 52000 N Load, NBR Seal, Polyamide Cage, 3450 rpm Maximum, -30 to 100 deg C
| Bore Diameter | : | 55 mm |
| Cage Material | : | Polyamide |
| Closure Type | : | Sealed |
| Load Capacity | : | 52000 N |
| Maximum Speed | : | 3450 rpm |
| Number of Rows | : | 2 |
| Outside Diameter | : | 120 mm |
| Seal Material | : | NBR |
| Series | : | 23 Series |
| Temperature Rating | : | -30 to 100 deg C |
| Type | : | Cylindrical Bore |
| Width | : | 43 mm |
- Self-aligning ball bearings are particularly suitable if there is skewing between the outer and inner ring
- Self-aligning ball bearings are particularly suitable for bearing arrangements with high radial loads
- Self-aligning ball bearings are particularly suitable for higher speeds on account of their point contact, than barrel roller bearings with line contact
- Contact seal on both sides
- Solid cage made from glass fiber reinforced polyamide PA66
- 52000 N dynamic/17900 N static
