FAG 23038-E1A-XL-M FAG23038E1AXLM
FAG 23038-E1A-XL-M 230..-E1A Cylindrical Bore Spherical Roller Bearing, 190 mm Dia Bore, 290 mm OD, 2 Rows, 75 mm W, 1080000 N Dynamic/1550000 N Static Load
- Manufacturer: Schaeffler Group
- Brand Name: FAG
- Part Number: FAG23038E1AXLM
- Alt Part Number: 23038-E1A-M
- MPN: 23038-E1A-XL-M
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
FAG spherical roller bearings have proved highly effective wherever high loads are present and there is a need to compensate for shaft deflections and/or misalignment of bearing seats.
FAG Spherical Roller Bearing, Cylindrical Bore, Series: 230..-E1A, 190 mm Bore Dia, 290 mm Outside Dia, 2 Rows, 75 mm W, Open Closure, 1080000 N Dynamic/1550000 N Static, Steel Bearing, Brass Cage, 2490 rpm Maximum, -30 to 200 deg C, Uncoated
| Bearing Material | : | Steel |
| Bore Diameter | : | 190 mm |
| Cage Material | : | Brass |
| Closure Type | : | Open |
| Finish | : | Uncoated |
| Load Capacity | : | 1080000 N Dynamic/1550000 N Static |
| Maximum Speed | : | 2490 rpm |
| Number of Rows | : | 2 |
| Outside Diameter | : | 290 mm |
| Series | : | 230..-E1A |
| Temperature Rating | : | -30 to 200 deg C |
| Type | : | Cylindrical Bore |
| Width | : | 75 mm |
- Higher performance bearing arrangements
- Lower operating costs
Specification Sheet
