FAG 22312-E1A-K-M FAG22312E1AXLKM
  1. pin-int

FAG 22312-E1A-K-M FAG22312E1AXLKM

FAG 22312-E1A-K-M 223..-E1 Tapered Bore Spherical Roller Bearing, 60 mm Dia Bore, 130 mm OD, 2 Rows, 46 mm W, 310000 N Dynamic/Static Load

  • Manufacturer: Schaeffler Group
  • Brand Name: FAG
  • Part Number: FAG22312E1AXLKM
  • MPN: 22312-E1A-K-M
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

FAG spherical roller bearings have proved highly effective wherever high loads are present and there is a need to compensate for shaft deflections and/or misalignment of bearing seats.

FAG Spherical Roller Bearing, Tapered Bore, Series: 223..-E1, 60 mm Bore Dia, 130 mm Outside Dia, 2 Rows, 46 mm W, Open Closure, 310000 N Dynamic/Static, Steel Bearing, Brass Cage, 5400 rpm Maximum, -30 to 200 deg C, Uncoated

Bearing Material      :      Steel
Bore Diameter      :      60 mm
Cage Material      :      Brass
Closure Type      :      Open
Finish      :      Uncoated
Load Capacity      :      310000 N Dynamic/Static
Maximum Speed      :      5400 rpm
Number of Rows      :      2
Outside Diameter      :      130 mm
Series      :      223..-E1
Temperature Rating      :      -30 to 200 deg C
Type      :      Tapered Bore
Width      :      46 mm
  • Higher performance bearing arrangements
  • Lower operating costs
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/FAG_22312_E1A_K_M_Specification_Sheet.pdf
