FAG 22212-E1-XL-K-C3 FAG22212E1XLKC3
FAG 22212-E1-XL-K-C3 222..-E1-K Tapered Bore Spherical Roller Bearing, 60 mm Dia Bore, 110 mm OD, 2 Rows, 28 mm W, 160000 N Dynamic/155000 N Static Load
- Manufacturer: Schaeffler Group
- Brand Name: FAG
- Part Number: FAG22212E1XLKC3
- MPN: 22212-E1-XL-K-C3
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
FAG spherical roller bearings have proved highly effective wherever high loads are present and there is a need to compensate for shaft deflections and/or misalignment of bearing seats.
FAG Spherical Roller Bearing, Tapered Bore, Series: 222..-E1-K, 60 mm Bore Dia, 110 mm Outside Dia, 2 Rows, 28 mm W, Open Closure, 160000 N Dynamic/155000 N Static, Steel Bearing, Steel Cage, 8100 rpm Maximum, -30 to 200 deg C, Uncoated
| Bearing Material | : | Steel |
| Bore Diameter | : | 60 mm |
| Cage Material | : | Steel |
| Closure Type | : | Open |
| Finish | : | Uncoated |
| Load Capacity | : | 160000 N Dynamic/155000 N Static |
| Maximum Speed | : | 8100 rpm |
| Number of Rows | : | 2 |
| Outside Diameter | : | 110 mm |
| Series | : | 222..-E1-K |
| Temperature Rating | : | -30 to 200 deg C |
| Type | : | Tapered Bore |
| Width | : | 28 mm |
- Higher performance bearing arrangements
- Lower operating costs
- C3 radial internal clearance
