Dodge® 481879 DOD481879
8MX-28S-12-1108 Dodge® 481879 HT500 High Torque Belt Sprocket, 1/2 to 1-1/8 in Taper-Lock® Bore, 2.744 in OD, 28 Grooves, 2.807 in Dia Pitch, 0.85 in W Face
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD481879
- Alt Part Number: 8MX-28S-12-1108
- MPN: 481879
- UPC: 782476697938
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
The Dodge® high torque HT500 synchronous drive product line utilizes a modified curvilinear tooth profile to delivers high torque, low maintenance and high energy efficiency with less overhung load than V-belt drives. The HT500 product family features a complete offering of synchronous sprockets with shaft attachment options including taper-lock and QD bushings (fin fan), as well as minimum plain bore sprockets (MPB) and idler sprockets available from stock.
Dodge® High Torque Belt Sprocket, Series: HT500, Taper-Lock® Bore, 1/2 to 1-1/8 in Bore Dia, 2.744 in Outside Dia, 2.807 in, 28 Grooves, 8 mm Pitch, 0.85 in Face Width, 3.207 in Flange Dia, Taper-Lock® Bushing
| Bore Diameter | : | 1/2 to 1-1/8 in |
| Bore Type | : | Taper-Lock® |
| Bushing Type | : | Taper-Lock® |
| Face Width | : | 0.85 in |
| Flange Diameter | : | 3.207 in |
| Number of Grooves | : | 28 |
| Outside Diameter | : | 2.744 in |
| Pitch Diameter | : | 2.807 in |
| Pitch | : | 8 mm |
| Series | : | HT500 |
- 5% or more energy efficient
- More torque with less belts
- Compact design
- Less maintenance
- Less belt pull
- Synchronous belts do not need to be re-tensioned after it is installed HT500 belt runs slip free requiring less maintenance and re-tensioning
- HT500 belts operate in wet, dusty and oily environments, it also has the capability to handle higher temperature than V-belts
- No lubrication required when compared to roller chain drives savings opportunity
- Ideal to convert legacy 20 mm HTD drive system cost savings opportunity with drive optimization
