Dodge® 455872 DOD455872
Dodge® 455872 Arm Heavy Duty Type D Sheave, 1-1/2 to 4-1/2 in QD® Bore, 50 in OD, 5 Grooves, 50 in Dia Pitch, 5.37 in W Face
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD455872
- Alt Part Number: 5C50.0-J
- MPN: 455872
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Dodge® branded sheaves come in two bushing styles, QD and Taper Lock®. In addition to these bushing choices, Dodge® now offers choices within our QD sheaves line. Our QD sheave line comes in a standard duty and a heavy duty offering.
Dodge® Sheave, Arm Heavy Duty Type D, QD® Bore, 1-1/2 to 4-1/2 in Bore, 50 in OD, 50 in Pitch Diameter, 5 Grooves, 5.37 in Face Width, 0.04 in Hub Projection, J Bushing, 5.41 in Overall Length, For Use With: C-Cross Section V-Belts, Iron, Gray
| Bore Diameter | : | 1-1/2 to 4-1/2 in |
| Bore Type | : | QD® |
| Bushing Type | : | J |
| Face Width | : | 5.37 in |
| Finish | : | Gray |
| Hub Projection | : | 0.04 in |
| Material | : | Iron |
| Number of Grooves | : | 5 |
| Outside Diameter | : | 50 in |
| Overall Length | : | 5.41 in |
| Pitch Diameter | : | 50 in |
| Suitable For Use With | : | C-Cross Section V-Belts |
| Type | : | Arm Heavy Duty Type D |
- Isolates shock loads and vibration
- Minor misalignment capability
- Drive ratios of 6:1 or more possible
- Low maintenance drive and no lubrication
- No lubrication required
- Typically 95% efficiency can be obtained
Instruction/Installation Manual
