Dodge® 23QZ25H56 DOD23QZ25H56
Dodge® E-Z Kleen® Tigear-2® 23QZ25H56 Right Angle Washdown Speed Reducer, Quill Input, Hollow Output, 1.65 hp, 25:1 Gear, 70 rpm Maximum Output, 1184 in-lb Torque Rating
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD23QZ25H56
- MPN: 23QZ25H56
- UPC: 782476049478
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Dodge® 23QZ25H56 is a helical worm right angle drive. Key specifications include gear ratio: 25:1, input: Quill, output: Hollow, and output size: 1.438 in. Tigear-2® E-Z Kleen® reducers offer superior corrosion resistance and sealing to meet the harsh wash-down applications associated with the food and beverage industry.
Dodge® E-Z Kleen® Tigear-2® Right Angle Washdown Speed Reducer, 25:1 Gear Ratio, 1.65 hp, Quill Input, Hollow Output, 1.438 in Output, 70 rpm Output Maximum, 1750 rpm Input Maximum, 1184 in-lb Torque, 2.31 in Centre Distance, 60 to 95 % Efficiency, Synthetic Oil Lubrication, Gray Iron, 9.94 in L x 5.65 in W x 9.31 in H Dimensions
| Centre Distance | : | 2.31 in |
| Dimensions | : | 9.94 in L x 5.65 in W x 9.31 in H |
| Efficiency | : | 60 to 95 % |
| Gear Ratio | : | 25:1 |
| Horsepower | : | 1.65 hp |
| Input Maximum Speed | : | 1750 rpm |
| Input Type | : | Quill |
| Lubrication Type | : | Synthetic Oil |
| Material | : | Gray Iron |
| Output Maximum Speed | : | 70 rpm |
| Output Size | : | 1.438 in |
| Output Type | : | Hollow |
| Torque Rating | : | 1184 in-lb |
- New worm shaft machining process increases gear precision and accuracy by more than twice the norm
- Precise plunge grinding process eliminates invisible lead and assures cool running
- Higher torque capacity
- Greater efficiency
- New bronze gear material has an extremely fine grain structure for maximum durability and minimum wear
- Coating system which provides greater than three times the corrosion resistance of standard epoxy painted units
- Two-piece harsh duty output seals
Specification Sheet
