Dodge® 22338 DOD022338
  1. pin-int

Dodge® 22338 DOD022338

Dodge® 22338 D-Flex Finished Bore Flexible Type SC Sleeve Coupling Hub, 05H Coupling, 1-1/16 in Dia Bore, 2 in Dia Hub, Steel

  • Manufacturer: Dodge Industrial
  • Brand Name: Dodge®
  • Part Number: DOD022338
  • MPN: 22338
  • UPC: 782475875122
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

Dodge® Sleeve Coupling Hub, Finished Bore Flexible Type SC, Series: D-Flex, 05H Coupling, 1-1/16 in Bore Dia, 2 in Hub Dia, 1.09 in Hub Length, 7600 rpm Maximum, 10 x 1-1/2 in Screw, Steel

Bore Diameter      :      1-1/16 in
Coupling Size      :      05H
Hub Diameter      :      2 in
Hub Length      :      1.09 in
Material      :      Steel
Maximum Speed      :      7600 rpm
Screw Size      :      10 x 1-1/2 in
Series      :      D-Flex
Type      :      Finished Bore Flexible Type SC
  • Rounded EPDM and neoprene element edges for full tooth engagement, even load distribution, reduced stress build up, and longer life
  • Outside diameter concentric to bore for ease in alignment
  • Interchangeable components makes installation quick and easy
  • No lubrication assures trouble-free operation
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Dodge_022338_Specification_Sheet.pdf
