Dodge® 1VP50X1-1/8 DOD1VP501 1/8
  1. pin-int

Dodge® 1VP50X1-1/8 DOD1VP501 1/8

Dodge® 1VP50X1-1/8 Type 2 Adjustable Pitch Sheave, 1-1/8 in Dia Bore, 4-3/4 in OD, 1 Grooves, 3.55 to 4.35 in (3L)/3.65 to 4.65 in (A/4L)/4.05 to 5.05 in (B/5L) Dia Pitch, 3/4 to 1-1/8 in W Face

  • Manufacturer: Dodge Industrial
  • Brand Name: Dodge®
  • Part Number: DOD1VP501 1/8
  • MPN: 1VP50X1-1/8
  • UPC: 775829145552
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Dodge® Adjustable Pitch Sheave, Type 2, Series: VP Series, 1-1/8 in Bore Dia, 4-3/4 in Outside Dia, 3.55 to 4.35 in (3L)/3.65 to 4.65 in (A/4L)/4.05 to 5.05 in (B/5L) Pitch Diameter, 1 Grooves, 3/4 to 1-1/8 in Face Width, 1-7/8 in Overall Length, For Use With: 3L/A, 4L/B, 5L Cross Section Belts, Cast Iron

Bore Diameter      :      1-1/8 in
Face Width      :      3/4 to 1-1/8 in
Material      :      Cast Iron
Number of Grooves      :      1
Outside Diameter      :      4-3/4 in
Overall Length      :      5-7/8 in
Pitch Diameter      :      3.55 to 4.35 in (3L)/3.65 to 4.65 in (A/4L)/4.05 to 5.05 in (B/5L)
Series      :      VP Series
Suitable For Use With      :      3L/A, 4L/B, 5L Cross Section Belts
Type      :      Type 2
  • Finished bore variable speed sheaves made of cast iron and designed for heavier duty service up to 25 hp
  • This model has positive locked-on settings
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Dodge_108371_Catalog.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Dodge_1VP50X1_1_8_Specification_Sheet.pdf
