Dodge® 128083 DOD128083
Dodge® 128083 204 Light/Intermediate Duty Non-Expansion Flange Mount Ball Bearing Unit, 3/4 in Dia Bore, 2.81 in Dia Bolt Circle, 3-Bolt Flange Mount, 3.56 in OAL/Dia
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD128083
- MPN: 128083
- UPC: 782475434251
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
Dodge® Flange Mount Ball Bearing Unit, Light/Intermediate Duty Non-Expansion, Series: 204, 3/4 in Bore, 2.81 in Diameter Bolt Circle, 3-Bolt Flange Mounting, 3.56 in Overall Length/Diameter, 1.04 in Overall Depth, 65 deg Set Screw Locking Device, Steel Bearing, Nitrile Rubber Seal, 2899 lb Dynamic/1482 lb Static Load, 7500 rpm Maximum, Zinc Plated
| Bearing Material | : | Steel |
| Bolt Circle Diameter | : | 2.81 in |
| Bore Diameter | : | 3/4 in |
| Finish | : | Zinc Plated |
| Flange Mounting Type | : | 3-Bolt |
| Load Capacity | : | 2899 lb Dynamic/1482 lb Static |
| Locking Device | : | 65 deg Set Screw |
| Maximum Speed | : | 7500 rpm |
| Overall Depth | : | 1.04 in |
| Overall Length/Diameter | : | 3.56 in |
| Seal Material | : | Nitrile Rubber |
| Series | : | 204 |
| Type | : | Light/Intermediate Duty Non-Expansion |
- DualGuard™ seal with rubberized flinger is standard
- Precision hardened and honed series 200 mounted ball bearings in globally interchangeable
- Unique 65 deg setscrew angle and premium cup point setscrews optimize shaft holding power without excessive inner ring distortion
- Narrow inner ring design
- Stamped steel housing
Specification Sheet
