Dodge® Taper-Lock® bushings are flangeless for clean, compact application. They are engineered with an 8 deg taper and a flush-mounted design with no protruding parts providing secure locking and elimination of wobble.
Dodge® Taper-Lock® Bushing, 1-5/8 in Bore, 8-1/2 in Diameter Hub, 8 deg Taper, 5.54 in Diameter Bolt Circle, 3 Bolt Holes, 5/8 x 1-3/4 in Screw, 77300 in-lb Torque, 4 in Overall Length, 3/8 x 3/16 in Keyway, Ductile Iron
| Bolt Circle Diameter | : | 5.54 in |
| Bore Diameter | : | 1-5/8 in |
| Hub Diameter | : | 8-1/2 in |
| Keyway Size | : | 3/8 x 3/16 in |
| Material | : | Ductile Iron |
| Number of Bolt Holes | : | 3 |
| Overall Length | : | 4 in |
| Screw Size | : | 5/8 x 1-3/4 in |
| Taper | : | 8 deg |
| Torque Rating | : | 77300 in-lb |
- World wide acceptance and availability
- Flush mounting
- Diamond D® integral key for added value and convenience
- Easy on and easy off design
- Clean and compact Taper-Lock® design
- 8 deg taper-grips tight, holds tight and runs true and no wobble
- 4040 coupling size
