Dodge® 115178 DOD115178
Dodge® 115178 Type A3 Sheave, 1/2 to 2-11/16 in Taper-Lock® Bore, 16.4 in OD, 2 Grooves, 16.4 in Dia Pitch, 2.37 in W Face
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD115178
- Alt Part Number: 2C16.0-2517
- MPN: 115178
- UPC: 782475090884
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Sheaves are manufactured in Dodge® plants under strict quality control assurances. Precision machining meets or exceeds joint extended belt life. Dodge® manufactures all sheaves in plants certified to ISO 9002 quality standards.
Dodge® Sheave, Type A3, Taper-Lock® Bore, 1/2 to 2-11/16 in Bore, 16.4 in OD, 16.4 in Pitch Diameter, 2 Grooves, 2.37 in Face Width, 2517 Bushing, For Use With: C-Cross Section V-Belts, Cast Iron, Gray
| Bore Diameter | : | 1/2 to 2-11/16 in |
| Bore Type | : | Taper-Lock® |
| Bushing Type | : | 2517 |
| Face Width | : | 2.37 in |
| Finish | : | Gray |
| Material | : | Cast Iron |
| Number of Grooves | : | 2 |
| Outside Diameter | : | 16.4 in |
| Pitch Diameter | : | 16.4 in |
| Suitable For Use With | : | C-Cross Section V-Belts |
| Type | : | Type A3 |
- Isolates shock loads and vibration
- Minor misalignment capability
- Drive ratios of 6:1 or more possible
- 1100 design hp at 1180 rpm/800 design hp at 1770 rpm stock drive selection
- Low maintenance
- No lubrication required
- Typically 95% efficiency can be obtained
