Dodge® 114544 DOD114544
  1. pin-int

Dodge® 114544 DOD114544

P60-14M-170-4545 Dodge® 114544 Flanged Solid Type A Belt Sprocket, 1-15/16 to 4-15/16 in Taper-Lock® Bore, 10.417 in OD, 10.527 in Dia Pitch, 7.38 in W Face

  • Manufacturer: Dodge Industrial
  • Brand Name: Dodge®
  • Part Number: DOD114544
  • Alt Part Number: P60-14M-170-4545
  • MPN: 114544
  • UPC: 782475745692
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Dodge® Belt Sprocket, Flanged Solid Type A, Taper-Lock® Bore, 1-15/16 to 4-15/16 in Bore Dia, 10.417 in Outside Dia, 10.527 in, 14 mm Pitch, 7.38 in Face Width, 11.067 in Flange Dia, 3/4 in/2.13 in Hub Projection, 4545 Bushing, 7.38 in Overall Length, For Use With: 170 mm W Type HT200 Belt

Bore Diameter      :      1-15/16 to 4-15/16 in
Bore Type      :      Taper-Lock®
Bushing Type      :      4545
Face Width      :      7.38 in
Flange Diameter      :      11.067 in
Hub Projection      :      3/4 in/2.13 in
Outside Diameter      :      10.417 in
Overall Length      :      7.38 in
Pitch Diameter      :      10.527 in
Pitch      :      14 mm
Suitable For Use With      :      170 mm W Type HT200 Belt
Type      :      Flanged Solid Type A
  • Torque rated shaft gripping strength to meet the higher demands of the 200% rating of HT200 belts
  • Compact save shaft space with compact taper lock design
  • Reduce overhung load compact design allows closer mounting to motor or reducer bearings, improves bearing life, reduces maintenance costs
  • Improves bearing life
  • Reduces maintenance costs
