Dodge® 100578 DOD100578
Dodge® 60BTL28H-2012 (100578) Single Strand Taper Lock® Type BTL Roller Chain Sprocket With Hardened Teeth, 1/2 in Dia Bore, 7.106 in OD, #60 Chain, 28 Teeth, 3/4 in Pitch, Low-Carbon Steel
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD100578
- Alt Part Number: 60BTL28H-2012
- MPN: 100578
- UPC: 782475049110
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Dodge® 60BTL28H-2012 (100578) is a Strand Taper Lock® Type BTL single pitch roller chain sprocket. Key specifications include chain size: #60, 28 teeth, bore: 1/2 in, and bushing type: Taper-Lock®. Roller chain drives have the ability to handle high shock loads and deliver dependable performance make them the drive of choice for many applications. Dodge® Taper-Lock® sprockets require no expensive or time-consuming re-matching. Their taper-bushing mount automatically compensates for variations in shaft and sprocket machining tolerances. With Dodge® Taper-Lock® sprockets, there are no protruding flanges or screw-heads to take up valuable shaft space. Their compact design provides for more power-dense packages.
Dodge® 60BTL28H-2012 (100578) Roller Chain Sprocket, Single Strand Taper Lock® Type BTL, 1/2 in Bore, 7.106 in OD, #60 Chain, 28 Teeth, 3/4 in Pitch, 6.7 in Pitch Diameter, 3.56 in Diameter Hub, 1-1/4 in Length Through Bore, Taper-Lock® Bushing, Low-Carbon Steel
| Bore Diameter | : | 1/2 in |
| Bushing Type | : | Taper-Lock® |
| Chain Size | : | #60 |
| Hub Diameter | : | 3.56 in |
| Length Through Bore | : | 1-1/4 in |
| Material | : | Low-Carbon Steel |
| Number of Teeth | : | 28 |
| Outside Diameter | : | 7.106 in |
| Pitch Diameter | : | 6.7 in |
| Pitch | : | 3/4 in |
| Type | : | Single Strand Taper Lock® Type BTL |
- No slip transmission
- Minimal overhung load on shaft bearings
- Generally used in lower speed ranges
- Low cost and rugged performance
- Compact drive design
- Installs easily
- Fits shaft securely
- Allows exact ratio and rating required for your operation
- Installation-ready, right from the box
- For 3/4 in pitch single strand chain
