Dodge® 079778 DOD079778
Dodge® 079778 212 Normal Duty Wide Inner Ring Screw Conveyor Hanger Ball Bearing, 2-7/16 in Dia Bore, Steel Bearing, 65 deg Set Screw Locking
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD079778
- Alt Part Number: SCHB-SC-207-HT
- MPN: 079778
- UPC: 782476917043
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
For over 65 years, Dodge® has provided innovative solutions for the industry's toughest mounted bearing applications. This experience led to the design of the most advanced mounted ball bearing product line in the industry. Dodge® ball bearings are built in our state-of-the-art facility in Rogersville, Tennessee using the latest manufacturing technologies to produce the highest quality product available on the market today.
Dodge® Screw Conveyor Hanger Ball Bearing, Normal Duty Wide Inner Ring, Series: 212, 2-7/16 in Bore, 11791 lb Dynamic/8100 lb Static Load, 65 deg Set Screw Locking, Steel Bearing, Polymer Cage, 3500 rpm Maximum, 225 to 400 deg F, Powder Coated
| Bearing Material | : | Steel |
| Bore Diameter | : | 2-7/16 in |
| Cage Material | : | Polymer |
| Finish | : | Powder Coated |
| Load Capacity | : | 11791 lb Dynamic/8100 lb Static |
| Locking Type | : | 65 deg Set Screw |
| Maximum Speed | : | 3500 rpm |
| Series | : | 212 |
| Temperature Rating | : | 225 to 400 deg F |
| Type | : | Normal Duty Wide Inner Ring |
- 65 deg setscrew locking system
- Precision hardened and honed inner and outer rings
- Wide inner ring design
- Cooler operation for longer grease life
- Grade 10 balls
