Dodge 070274 P2B-S2-108R Pillow Block Roller Bearing

Dodge® P2B-S2-108R (070274) Type S2000 Pillow Block Roller Bearing Unit, 1-1/2 in Dia Bore, 4.81 to 5.2 in L Bolt Center-to-Center, 1.88 in Base to Bore Centerline, 6.88 in OAL x 3.88 in OAH

  • Manufacturer: Dodge Industrial
  • Brand Name: Dodge®
  • Part Number: DOD070274
  • Alt Part Number: P2B-S2-108R
  • MPN: 070274
  • UPC: 782475305834
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Dodge® P2B-S2-108R (070274) is a type s2000 pillow block roller bearing unit with a 1-1/2 in round bore. It uses two-bolt base mounting, springlok™ concentric collar locking, a trident™ triple lip seal, and a non-expansion (fixed) design. Load capacity is 20800 lb Dynamic/21000 lb Static.

Dodge® P2B-S2-108R (070274) Pillow Block Roller Bearing Unit, Type S2000, 1-1/2 in Bore, 4.81 to 5.2 in Bolt Center-to-Center Length, 1.88 in Base to Bore Centerline, 6.88 in Overall Length, 2.53 in Overall Width, 3.88 in Overall Height, Two-Bolt Base Mounting, Round Bore, 1.95 in Base Width, Springlok™ Concentric Collar Locking Device, Trident™ Triple Lip Seal, Non-Expansion (Fixed), 20800 lb Dynamic/21000 lb Static Load, -100 to 200 deg F, 2900 rpm Maximum, Cast Iron, Black Oxide

Base Width      :      1.95 in
Base to Bore Centerline      :      1.88 in
Bolt Center-to-Center Length      :      4.81 to 5.2 in
Bore Diameter      :      1-1/2 in
Bore Type      :      Round
Expansion Type      :      Non-Expansion (Fixed)
Finish      :      Black Oxide
Load Capacity      :      20800 lb Dynamic/21000 lb Static
Locking Device      :      Springlok™ Concentric Collar
Material      :      Cast Iron
Maximum Speed      :      2900 rpm
Mounting Type      :      Two-Bolt Base
Overall Height      :      3.88 in
Overall Length      :      6.88 in
Overall Width      :      2.53 in
Seal Type      :      Trident™ Triple Lip
Temperature Rating      :      -100 to 200 deg F
Type      :      Type S2000
  • High-capacity double row spherical rollers
  • Permits static or dynamic misalignment up to +/- 1 deg
  • Factory sealed, lubed, and adjusted
  • Expansion capability up to 3/8 in
  • Flinger to shield seal and bearing from contamination/damage
  • Larger rollers
  • More contact area
  • Case-carburized inner rings resist cracking
