Dodge® 062443 DOD062443
SCHB-DL-115 Dodge® 062443 210 Series Normal Duty Wide Inner Ring Screw Conveyor Hanger Ball Bearing, 1-15/16 in Dia Bore, 4.63 in OD, 2.01 in Width, Steel Bearing, Alternate Part Number: SCHB-DL-115
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD062443
- Alt Part Number: SCHB-DL-115
- MPN: 062443
- UPC: 782475906871
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
For concentric grip on the shaft and less vibration at higher speeds, specify Dodge® D-LOK® normal or medium duty mounted ball bearings. These unique, concentric collar bearings are engineered with features that assure you superior holding power with improved concentricity. Even at high speeds, the D-LOK® bearing grips the shaft tighter and more uniformly for less vibration.
Dodge® Screw Conveyor Hanger Ball Bearing, Normal Duty Wide Inner Ring, Series: 210 Series, 1-15/16 in Bore Dia, 4.63 in Outside Dia, 2.01 in Width, 7891 lb Dynamic/5213 lb Static, Steel Bearing, Nylon Cage, 4500 rpm Maximum, 225 to 400 deg F, Powder Coated
| Bearing Material | : | Steel |
| Bore Diameter | : | 1-15/16 in |
| Cage Material | : | Nylon |
| Finish | : | Powder Coated |
| Load Capacity | : | 7891 lb Dynamic/5213 lb Static |
| Maximum Speed | : | 4500 rpm |
| Outside Diameter | : | 4.63 in |
| Series | : | 210 |
| Temperature Rating | : | 225 to 400 deg F |
| Type | : | Normal Duty Wide Inner Ring |
| Width | : | 2.01 in |
- Precision hardened and honed inner and outer rings
- New rugged housing design
- Dodge® DualGuard® positive contact seal including rubberized flingers
- Stronger, flexible ball retainer
- Simplified anti-rotation device
- Electrostatically applied epoxy paint
- Corrosion resistant insert
Specification Sheet
