Dodge® 057878 DOD057878

Dodge® 057878 206 Normal Duty Hanger Ball Bearing Unit, 1 in Dia Bore, 4.06 in OD, 1.52 in W, Stainless Steel Bearing, Set Screw Collar Locking, Alternate Part Number: SCHB-SC-100 MOD

  • Manufacturer: Dodge Industrial
  • Brand Name: Dodge®
  • Part Number: DOD057878
  • Alt Part Number: SCHB-SC-100 MOD
  • MPN: 057878
  • UPC: 782475148998
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Dodge® Hanger Ball Bearing Unit, Normal Duty, Series: 206, 1 in Bore, 4.06 in OD, 1.52 in Width, 3146 lb Dynamic/1769 lb Static Load, Set Screw Collar Locking, Stainless Steel Bearing, 6500 rpm Maximum, 225 to 400 deg F

Bearing Material      :      Stainless Steel
Bore Diameter      :      1 in
Load Capacity      :      3146 lb Dynamic/1769 lb Static
Locking Type      :      Set Screw Collar
Maximum Speed      :      6500 rpm
Outside Diameter      :      4.06 in
Series      :      206
Temperature Rating      :      225 to 400 deg F
Type      :      Normal Duty
Width      :      1.52 in
  • DualGuard™ seal with rubberized flinger is standard
  • Precision hardened and honed setscrew mounted ball bearings in globally interchangeable
  • Unique 65 deg setscrew angle and premium cup point setscrews optimize shaft holding power without excessive inner ring distortion
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/ABB_0508160_Catalog.pdf
