Dodge® 033202 DOD033202
F4B-LT10-015 Dodge® 033202 LT1000 Series Non-Expansion Solidlube Flange Plain Sleeve Bearing, 15/16 in Dia Bore, 2-3/4 in L Bolt Center-to-Center, 3-7/8 in Dia Bolt Circle, 4-Bolt Base Flange Mount, 3-3/4 in OAL/Dia, Alternate Part Number: F4B-LT10-015
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD033202
- MPN: 033202
- UPC: 782475016310
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
Dodge® Flange Plain Sleeve Bearing, Non-Expansion Solidlube, Series: LT1000 Series, 15/16 in Bore Dia, 2-3/4 in Bolt Center-to-Center Length, 3-7/8 in Bolt Circle, 4-Bolt Base Flange Mounting Type, 3-3/4 in Overall Length/Diameter, 1-1/8 in Overall Depth, 3-3/4 in Overall Height, Steel Bearing, 750 lb, 1900 rpm Maximum, -200 to 1000 deg F, Powder Coated
| Bearing Material | : | Steel |
| Bolt Center-to-Center Length | : | 2-3/4 in |
| Bolt Circle Diameter | : | 3-7/8 in |
| Bore Diameter | : | 15/16 in |
| Finish | : | Powder Coated |
| Flange Mounting Type | : | 4-Bolt Base |
| Load Capacity | : | 750 lb |
| Maximum Speed | : | 1900 rpm |
| Overall Depth | : | 1-1/8 in |
| Overall Height | : | 3-3/4 in |
| Overall Length/Diameter | : | 3-3/4 in |
| Series | : | LT1000 |
| Temperature Rating | : | -200 to 1000 deg F |
| Type | : | Non-Expansion Solidlube |
- Good in temperature extremes and inaccessible locations
- Will function effectively in a vacuum
- Ideal where bearings are subject to dry cycles or where lube systems would be too costly
- Usable in many corrosive medias
- Will operate in submersible applications of some low viscosity liquids
- Recommended for slow speeds and limited shaft movement applications
Specification Sheet
