Dodge® 032957 DOD032957
Dodge® 032957 LT700 Solidlube Pillow Block Plain Sleeve Bearing, 2-3/16 in Dia Bore, 6-3/8 to 7-7/16 in L Bolt Center-to-Center, 2-7/16 in Base to Bore Centerline, 8-7/8 in OAL x 4-29/32 in OAH, Alternate Part Number: P2B-LTB7-203
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD032957
- Alt Part Number: P2B-LTB7-203
- MPN: 032957
- UPC: 782475015795
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Dodge® Pillow Block Plain Sleeve Bearing, Solidlube, Series: LT700, 2-3/16 in Bore, 6-3/8 to 7-7/16 in Bolt Center-to-Center Length, 2-7/16 in Base to Bore Centerline, 8-7/8 in Overall Length, 1-3/4 in Overall Width, 4-29/32 in Overall Height, Two-Bolt Base Mounting, Round Bore, 2-5/16 in Base Width, Unsealed Seal, Non-Expansion (Fixed), -40 to 700 deg F, 1100 rpm Maximum, Cast Iron, Powder Coated
| Base Width | : | 2-5/16 in |
| Base to Bore Centerline | : | 2-7/16 in |
| Bolt Center-to-Center Length | : | 6-3/8 to 7-7/16 in |
| Bore Diameter | : | 2-3/16 in |
| Bore Type | : | Round |
| Expansion Type | : | Non-Expansion (Fixed) |
| Finish | : | Powder Coated |
| Material | : | Cast Iron |
| Maximum Speed | : | 1100 rpm |
| Mounting Type | : | Two-Bolt Base |
| Overall Height | : | 4-29/32 in |
| Overall Length | : | 8-7/8 in |
| Overall Width | : | 1-3/4 in |
| Seal Type | : | Unsealed |
| Series | : | LT700 |
| Temperature Rating | : | -40 to 700 deg F |
| Type | : | Solidlube |
- Self lubricating, statically self-aligning bearings for extreme industrial applications
- Good in temperature extremes and inaccessible locations
- Will function effectively in a vacuum
- Ideal where bearings are subject to dry cycles or where lube systems would be too costly
- Usable in many corrosive medias
- Will operate in submersible applications of some low viscosity liquids
- Recommended for slow speeds and limited shaft movement applications
Instruction/Installation Manual
