Dodge® 023221 DOD023221
Dodge® 023221 203 Double-Interlock Non-Expansion Triple Lip Type K Flange Mount Roller Bearing Unit, 2-3/16 in Dia Bore, 5.66 in L Bolt Center-to-Center, 8 in Dia Bolt Circle, 4-Bolt Base Flange Mount, 7.81 in OAL/Dia, Alternate Part Number: F4B-K-203R
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD023221
- Alt Part Number: F4B-K-203R
- MPN: 023221
- UPC: 782475699759
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
Dodge® Flange Mount Roller Bearing Unit, Double-Interlock Non-Expansion Triple Lip Type K, Series: 203, 2-3/16 in Bore, 5.66 in Bolt Center-to-Center Length, 8 in Diameter Bolt Circle, 4-Bolt Base Flange Mounting, 7.81 in Overall Length/Diameter, 3.31 in Overall Depth, 7.81 in Overall Height, 65 deg Set Screw Locking Device, Cast Iron Bearing, 9850 lb Dynamic/48200 lb Static Load, 2730 rpm Maximum, -100 to 200 deg F, Uncoated
| Bearing Material | : | Cast Iron |
| Bolt Center-to-Center Length | : | 5.66 in |
| Bolt Circle Diameter | : | 8 in |
| Bore Diameter | : | 2-3/16 in |
| Finish | : | Uncoated |
| Flange Mounting Type | : | 4-Bolt Base |
| Load Capacity | : | 9850 lb Dynamic/48200 lb Static |
| Locking Device | : | 65 deg Set Screw |
| Maximum Speed | : | 2730 rpm |
| Overall Depth | : | 3.31 in |
| Overall Height | : | 7.81 in |
| Overall Length/Diameter | : | 7.81 in |
| Series | : | 203 |
| Temperature Rating | : | -100 to 200 deg F |
| Type | : | Double-Interlock Non-Expansion Triple Lip Type K |
- Offers tapered roller bearing durability in a variety of mounting styles
- XTS triple-lip seal standard
- Extra protection E-Tect seal option
- Factory assembled, adjusted and lubricated shaft
- Self-aligning
