Dodge® 023161 DOD023161
  1. pin-int

Dodge® 023161 DOD023161

Dodge® 023161 307 Non-Expansion Type E-Xtra Top Angle Take-Up Roller Bearing, 3-3/16 in Dia Bore, 9-1/2 in L x 5 in W x 9.63 in H, 17750 lb Dynamic/108600 lb Static Load, Alternate Part Number: TP-E-303R

  • Manufacturer: Dodge Industrial
  • Brand Name: Dodge®
  • Part Number: DOD023161
  • MPN: 023161
  • UPC: 782475698844
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

Type E-Xtra bearings are manufactured with high-capacity tapered roller bearing inserts which allow for combination of radial and thrust loads, featuring the highest load ratings in the industry achieved by world class design and manufacturing.

Dodge® Top Angle Take-Up Roller Bearing, Non-Expansion Type E-Xtra, Series: 307, 3-3/16 in Bore, 9-1/2 in Length, 5 in Width, 9.63 in Height, 17750 lb Dynamic/108600 lb Static Load, For Use With: TP50 Top Angle Take-Up Frame, Steel Bearing, -100 to 200 deg F

Bearing Material      :      Steel
Bore Diameter      :      3-3/16 in
Height      :      9.63 in
Length      :      9-1/2 in
Load Capacity      :      17750 lb Dynamic/108600 lb Static
Series      :      307
Suitable For Use With      :      TP50 Top Angle Take-Up Frame
Temperature Rating      :      -100 to 200 deg F
Type      :      Non-Expansion Type E-Xtra
Width      :      5 in
  • Exclusive Baldor-Dodge® XTS triple lip seal protects against contamination in dusty or wet environments
  • Oversized dual Springlok™ collars act as fingers for added protection
  • Bearings are completely assembled, factory adjusted and pre-lubricated
  • Case hardened rollers and races
  • 65 deg setscrew angle Springlok™ collar/ flingers - more holding power than 90 to 120 deg
