Dodge® 013112 DOD013112
Dodge® 013112 DGF Series Type EB Gear Coupling Rigid Hub, Code 1 Coupling, 0.438 to 2.188/0.438 to 2.313 in Dia Bore, 1-11/16 in L Through Bore, 2-5/16 in Dia Hub, Steel
- Manufacturer: Dodge Industrial
- Brand Name: Dodge®
- Part Number: DOD013112
- Alt Part Number: DGF 1.0 RIGID HUB EB
- MPN: 013112
- UPC: 782475318162
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Dodge® 013112 is a Series DGF Type EB gear coupling hub. Key specifications include coupling size: Code 1, bore: 0.438 to 2.188/0.438 to 2.313 in, hub diameter: 2-5/16 in, and length through bore: 1-11/16 in.
Dodge® Gear Coupling Rigid Hub, Type EB, Series: DGF Series, Code 1 Coupling, 0.438 to 2.188/0.438 to 2.313 in Bore Dia, 2-5/16 in Hub Dia, 6000 rpm Maximum, 1-11/16 in Length Through Bore, Steel
| Bore Diameter | : | 0.438 to 2.188/0.438 to 2.313 in |
| Coupling Size | : | Code 1 |
| Hub Diameter | : | 2-5/16 in |
| Length Through Bore | : | 1.6875 in |
| Material | : | Steel |
| Maximum Speed | : | 6000 rpm |
| Series | : | DGF |
| Type | : | Type EB |
- Larger tooth profile provides additional service factor
- Good inherent balance
- Proven O-ring seal design
- Machined flanges and gasket for improved sealing
- High-grade fasteners
- High torque rating allows for coupling downsizing
- Versatile design permits interchangeable half couplings
- Low backlash
- Crowned tooth profile for longer life and improved performance
Line Drawing
