ContiTech Y-90S-SK GOOY-90S-SK
ContiTech SilentSync® Y-90S-SK Type 4 Synchronous Sprocket, 1/2 to 2-5/8 in Taper-Lock/QD Bore, 8.969 in OD, 90 Grooves, 9.023 in Dia Pitch, 0.669 in W Face
- Manufacturer: ContiTech AG
- Brand Name: ContiTech
- Part Number: GOOY-90S-SK
- MPN: Y-90S-SK
- UPC: 037256183096
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
SilentSync® sprockets have been designed to ensure maximum service life and performance. Over 1500 sprocket combinations are available, making it easier to match the desired design speed. More speed ratio options also means more design flexibility and more compact drives.
ContiTech SilentSync® Synchronous Sprocket, Type 4, Taper-Lock/QD Bore, 1/2 to 2-5/8 in Bore Dia, 8.969 in Outside Dia, 9.023 in, 90 Grooves, 8 mm Pitch, 0.669 in Face Width, SK Bushing, 2.03 in Overall Length, Cast Iron, Yellow
| Bore Diameter | : | 1/2 to 2-5/8 in |
| Bore Type | : | Taper-Lock/QD |
| Bushing Type | : | SK |
| Face Width | : | 0.669 in |
| Finish | : | Yellow |
| Material | : | Cast Iron |
| Number of Grooves | : | 90 |
| Outside Diameter | : | 8.969 in |
| Overall Length | : | 2.03 in |
| Pitch Diameter | : | 9.023 in |
| Pitch | : | 8 mm |
| Type | : | Type 4 |
- More design flexibility with more compact drives
- No flanges
- Self-tracking design
- Up to 25% more power capacity
- Static conductivity
- Up to 98% energy efficiency
- Is a patented drive system well suited for many high-end, high horsepower drive applications
- Has a wide range of operating temperatures for greater versatility
