Browning® 766826 BROVTBE123
  1. pin-int

Browning® 766826 BROVTBE123

Browning® 766826 VTBE 100 Intermediate Duty Pillow Block Ball Bearing Unit, 1-7/16 in Dia Bore, 3-1/4 in L Bolt Center-to-Center, 1-7/8 in Base to Bore Centerline, 4-1/4 in OAL x 3-3/4 in OAH

  • Manufacturer: Regal Rexnord
  • Brand Name: Browning®
  • Part Number: BROVTBE123
  • Alt Part Number: VTBE-123
  • MPN: 766826
  • UPC: 662460339443
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Browning® mounted ball bearings feature multiple housing styles, materials and configurations, an extended inner race insert bearing with ball riding nylon retainer. The insert features a rivet to prevent outer ring rotation and is available with setscrew, eccentric or BOA concentric locking collar. The contact seal with black oxide treated flinger provides a good balance between contaminant resistance, grease loss and friction.

Browning® Pillow Block Ball Bearing Unit, Intermediate Duty, Series: VTBE 100, 1-7/16 in Bore, 3-1/4 in Bolt Center-to-Center Length, 1-7/8 in Base to Bore Centerline, 4-1/4 in Overall Length, 3-3/4 in Overall Height, Tapped Base Mounting, Round Bore, 1-7/8 in Base Width, Eccentric Locking Device, Single Lip Seal, Non-Expansion (Fixed) Expansion, 5782 lb Dynamic/3493 lb Static Load, 200 to 250 deg F, 2500 rpm Maximum, Cast Iron, Gray Painted

Base Width      :      1-7/8 in
Base to Bore Centerline      :      1-7/8 in
Bolt Center-to-Center Length      :      3-1/4 in
Bore Diameter      :      1-7/16 in
Bore Type      :      Round
Expansion Type      :      Non-Expansion (Fixed)
Finish      :      Gray Painted
Load Capacity      :      5782 lb Dynamic/3493 lb Static
Locking Device      :      Eccentric
Material      :      Cast Iron
Maximum Speed      :      2500 rpm
Mounting Type      :      Tapped Base
Overall Height      :      3-3/4 in
Overall Length      :      4-1/4 in
Seal Type      :      Single Lip
Series      :      VTBE 100
Temperature Rating      :      200 to 250 deg F
Type      :      Intermediate Duty
  • An anti-rotation rivet prevents outer ring creep or rotation within the housing
  • Semi solid cast iron rugged base design provides an excellent mounting foundation
  • Eccentric locking design incorporates a precision eccentric collar to mate with the inner ring extension for shaft holdAlemite fitting lubrication
  • Powder coat epoxy cast iron housing
  • Eccentric locking designed for locking in direction of rotation
  • pdfWarranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_A175382_Warranty.pdf
