Browning® 766185 BROVPB222
  1. pin-int

Browning® 766185 BROVPB222

Browning® 766185 VPB 200 Normal Duty High Base Pillow Block Ball Bearing Unit, 1-3/8 in Dia Bore, 4-5/8 to 5-3/8 in L Bolt Center-to-Center, 1-7/8 in Base to Bore Centerline, 6-3/4 in OAL x 3-11/16 in OAH

  • Manufacturer: Regal Rexnord
  • Brand Name: Browning®
  • Part Number: BROVPB222
  • Alt Part Number: VPB-222
  • MPN: 766185
  • UPC: 662460345970
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Browning® mounted ball bearings feature multiple housing styles, materials and configurations, an extended inner race insert bearing with ball riding nylon retainer. The insert features a rivet to prevent outer ring rotation and is available with setscrew, eccentric or BOA concentric locking collar. The contact seal with black oxide treated flinger provides a good balance between contaminant resistance, grease loss and friction.

Browning® Pillow Block Ball Bearing Unit, Normal Duty High Base, Series: VPB 200, 1-3/8 in Bore, 4-5/8 to 5-3/8 in Bolt Center-to-Center Length, 1-7/8 in Base to Bore Centerline, 6-3/4 in Overall Length, 3-11/16 in Overall Height, Two-Bolt Base Mounting, Round Bore, 1-3/4 in Base Width, BOA Concentric Locking Device, Single Lip Contact with Flinger Seal, Non-Expansion (Fixed) Expansion, 5782 lb Dynamic/3493 lb Static Load, 200 to 250 deg F, 4000 rpm Maximum, Cast Iron, Gray Painted

Base Width      :      1-3/4 in
Base to Bore Centerline      :      1-7/8 in
Bolt Center-to-Center Length      :      4-5/8 to 5-3/8 in
Bore Diameter      :      1-3/8 in
Bore Type      :      Round
Expansion Type      :      Non-Expansion (Fixed)
Finish      :      Gray Painted
Load Capacity      :      5782 lb Dynamic/3493 lb Static
Locking Device      :      BOA Concentric
Material      :      Cast Iron
Maximum Speed      :      4000 rpm
Mounting Type      :      Two-Bolt Base
Overall Height      :      3-11/16 in
Overall Length      :      6-3/4 in
Seal Type      :      Single Lip Contact with Flinger
Series      :      VPB 200
Temperature Rating      :      200 to 250 deg F
Type      :      Normal Duty High Base
  • An anti-rotation rivet prevents outer ring creep or rotation within the housing
  • Semi solid cast iron rugged base design provides an excellent mounting foundation
  • BOA is a concentric locking collar clamp design that results in near-perfect concentricity of the shaft to the bearing bore
  • Nylon retainer
  • 52100 steel insert
  • Alemite fitting lubrication
  • Powder coat epoxy cast iron housing
  • pdfWarranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Browning_A175382_Warranty.pdf
