Browning® 1174325 BROD50P15
Browning® 1174325 Double Strand Roller Chain Sprocket With Hardened Teeth, 1/2 to 1-3/4 in Dia Bore, 3.315 in OD, 50 Chain, 15 Teeth, 5/8 in Pitch, Steel
- Manufacturer: Regal Rexnord
- Brand Name: Browning®
- Part Number: BROD50P15
- Alt Part Number: D50P15
- MPN: 1174325
- UPC: 662289209026
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.
Browning® Roller Chain Sprocket, Double Strand, 1/2 to 1-3/4 in Bore Dia, 3.315 in Outside Dia, 50 Chain, 15 Teeth, 5/8 in Pitch, 3.006 in, 3 in Hub Dia, 2-15/16 in Length Through Bore, Type P2 Split Taper Bushing, Steel
| Bore Diameter | : | 1/2 to 1-3/4 in |
| Bushing Type | : | Type P2 Split Taper |
| Chain Size | : | 50 |
| Hub Diameter | : | 3 in |
| Length Through Bore | : | 2-15/16 in |
| Material | : | Steel |
| Number of Teeth | : | 15 |
| Outside Diameter | : | 3.315 in |
| Pitch Diameter | : | 3.006 in |
| Pitch | : | 5/8 in |
| Type | : | Double Strand |
- Item Features 01=External key have higher torque capacity, aligns bolt holes
- Item Features 02=Provides key to key drive
- Item Features 03=Double split barrel to improved clamping
- Item Features 04=Solid flange true concentricity, easy installation
- Item Features 05=Longer barrel have better support on the shaft
- Item Features 06=For use with 5/8 in pitch ANSI roller chain
- Item Features 07=Browning offers one of the largest selection of application shaft ready sprockets in the industry
- Item Features 08=Easy Installation and removal
- Item Features 09=Split Taper Bushing are available in popular Inch, Metric and Spline bore
- Item Features 10=Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain
