Browning® 1012301 BRO8C94R
  1. pin-int

Browning® 1012301 BRO8C94R

Browning® 1012301 Type 15 Web Multiple Sheave, 1.38 to 3.625 in Split Taper Bore, 9.8 in OD, 8 Grooves, 9.8 in Dia Pitch, 8-1/4 in W Face

  • Manufacturer: Regal Rexnord
  • Brand Name: Browning®
  • Part Number: BRO8C94R
  • Alt Part Number: 8C94R
  • MPN: 1012301
  • UPC: 662289266050
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Browning® offers an extensive multi-groove sheave offering. This includes Browning® Split-Taper® and QD® bushing designs. This means maximum economy and versatility for your application. Truly the right drive every time our exclusive B5V® sheaves have a patented design that offers 5V horsepower in the economy of a B section sheave. B5V® sheaves serve 90% of all applications from 10 to 150 hp. This can reduce cost up to 40% over traditional designs.

Browning® Multiple Sheave, Type 15 Web, Split Taper Bore, 1.38 to 3.625 in Bore, 9.8 in OD, 9.8 in Pitch Diameter, 8 Grooves, 8-1/4 in Face Width, R2 Bushing, 8-1/4 in Overall Length, For Use With: GripBelt® C Cross Section V-Belt, Cast Iron

Bore Diameter      :      1.38 to 3.625 in
Bore Type      :      Split Taper
Bushing Type      :      R2
Face Width      :      8-1/4 in
Material      :      Cast Iron
Number of Grooves      :      8
Outside Diameter      :      9.8 in
Overall Length      :      8-1/4 in
Pitch Diameter      :      9.8 in
Suitable For Use With      :      GripBelt® C Cross Section V-Belt
Type      :      Type 15 Web
  • Incorporates Browning® Split-Taper® bushing the only bushing system that provides a true key-to-key drive to both the shaft and the hub
  • All sheaves are statically balanced to assure smooth and vibration free performance
  • Close grain cast iron allows Browning® to machine our sheaves to the closest tolerances possible
