| Enclosure Type | : | TEFC |
| Frame | : | 145TC |
| Frequency Rating | : | 60 Hz |
| Horsepower | : | 2 hp |
| Insulation Class | : | F |
| Mounting Type | : | C-Face and Feet |
| Phase | : | 3 |
| Service Factor | : | 1.25 |
| Shaft Size | : | 0.875 in |
| Speed | : | 1735 rpm |
| Torque Rating | : | 6.05 ft-lb |
| Voltage Rating | : | 230/460 VAC |
- Type: General Purpose
- Horsepower (hp): 2
- KW: 1.5
- Speed (rpm): 1735
- Voltage Rating (VAC): 230/460
- Frequency Rating (Hz): 60
- Enclosure Type: TEFC
- Frame: 145TC
- Mounting Type: C-Face and Feet
- NEMA Design: B
- Nom Efficiency: 86.5
- Insulation Class: F
- KVA Code: H
- Phase: 3
- Service Factor: 1.25
- FLA: 2.65
- Frame Material: Cast Iron
- Torque Rating(ft-lb): 6.05
- Grease: Lithium Based
- Duty: S1
- Dual Mounting Holes?: Yes
- DE Bearing: 6205ZZC3
- NDE Bearing: 6203ZZC3
- Ambient Temp: -20 to 40
- 208V Amps: 5.86057692307692
- Usable 208V: Yes
- Rotation: Reversible
- Number of Leads: 9
- Orientation: Horizontal or Vertical
- Poles: 4
- Power Factor: 0.82
- CSA Certified: Yes
- FL Temp Rise: 80
- Temp Code: T3
- Temp Code SW: T3
- Temp Code VFD: T3
- VFD VT Ratio: 10:1
- VFD CT Ratio: 5:1
- VFD VT Hz: 6-60
- VFD CT Hz: 12-60
- XP Rating: Class 1, Div 2, Groups A,B,C,D Zone 2, Groups IIA & IIB T3
- Conduit Box Orientation: F1
- Protection (IP): 55
- C-Dimension (inch): 14.2
- Shaft Length (inch): 2.25
- Shaft Size (inches): 0.875
- Country Of Origin: China
