Brewer Universal Drive Tensioner B6013H BREB6013H
  1. pin-int

Brewer Universal Drive Tensioner B6013H BREB6013H

Brewer Universal Drive Tensioner B6013H A-Style Single Strand Idler Roller Chain Sprocket With Ball Bearing, 5/8 in Dia Bore, 3.49 in OD, 60 Chain, 13 Teeth, 3/4 in Pitch, Steel

  • Manufacturer: Brewer Machine and Gear
  • Brand Name: Brewer Universal Drive Tensioner
  • Part Number: BREB6013H
  • MPN: B6013H
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

Brewer Universal Drive Tensioner Idler Roller Chain Sprocket, A-Style Single Strand, 5/8 in Bore Dia, 3.49 in Outside Dia, 60 Chain, 13 Teeth, 3/4 in Pitch, 0.72 in Length Through Bore, Steel

Bore Diameter      :      5/8 in
Chain Size      :      60
Length Through Bore      :      0.72 in
Material      :      Steel
Number of Teeth      :      13
Outside Diameter      :      3.49 in
Pitch      :      3/4 in
Type      :      A-Style Single Strand
  • Ball bearing idler sprockets are machined all over with hardened teeth
  • The deep groove ball bearings are precision ground, double-sealed and pre-lubricated
  • Compatible with a wide array of mounts and idler shafts
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Brewer_B3520H_Specification_Sheet.pdf
