NTN BCA® wide series bearings are manufactured with an inner ring that extends equally on both sides of the bearing. The additional shaft support afforded by the wider ring promotes exceptional performance in more heavily loaded and higher speed applications. The extra width also permits the use of seals that extend past the outer ring face resulting in a larger internal cavity for a greater initial pack of lubricant. WP series are supplied with a mating eccentric locking collar.
BCA® Ball Insert Bearing, Round Bore, Series: WPS, 36.513 mm Bore, 72 mm OD, 51.294 mm Width, Double Seal Closure, 25700 N Load, Hardened Steel Bearing, Nitrile Rubber Seal, 2250 rpm Maximum, -40 to 120 deg C
| Bearing Material | : | Hardened Steel |
| Bore Diameter | : | 36.513 mm |
| Closure Type | : | Double Seal |
| Load Capacity | : | 25700 N |
| Maximum Speed | : | 2250 rpm |
| Outside Diameter | : | 72 mm |
| Seal Material | : | Nitrile Rubber |
| Series | : | WPS |
| Temperature Rating | : | -40 to 120 deg C |
| Type | : | Round Bore |
| Width | : | 51.294 mm |
- CN radial clearance
- Steel ball
- Relubricatable
- Contact seal
- Wide single lip seal
- Precision grounded
- Spherical OD
- 25700 N dynamic/15300 N static
