Barden 203T5 O-11 BAR203T5
  1. pin-int

Barden 203T5 O-11 BAR203T5

Barden 203T5 O-11 Deep Groove Spindle Bearing, 17 mm Dia Bore, 40 mm OD, 1 Row, 12 mm W, 9.39 kN Dynamic/5.6 kN Static Load

  • Manufacturer: Schaeffler Group
  • Brand Name: Barden
  • Part Number: BAR203T5
  • MPN: 203T5 O-11
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Deep groove ball bearings have full shoulders on both sides of the raceways of the inner and outer rings. They can accept radial loads, thrust loads in either direction, or a combination of loads. The full shoulders and the cages used in deep groove bearings make them suitable for the addition of closures. Besides single deep groove bearings with closures, Barden also offers duplex pairs with seals or shields on the outboard faces.

Barden Deep Groove Spindle Bearing, 17 mm Bore Dia, 40 mm Outside Dia, 1 Row, 12 mm W, Open Closure, 9.39 kN Dynamic/5.6 kN Static, Steel Bearing, Aluminum/Phenolic Resin Cage, 59000 rpm Maximum, 300 deg F

Bearing Material      :      Steel
Bore Diameter      :      17 mm
Cage Material      :      Aluminum/Phenolic Resin
Closure Type      :      Open
Load Capacity      :      9.39 kN Dynamic/5.6 kN Static
Maximum Speed      :      59000 rpm
Number of Rows      :      1
Outside Diameter      :      40 mm
Temperature Rating      :      300 deg F
Width      :      12 mm
  • Winsorlube L-245X oil lubrication
  • ABEC 7 nominal tolerances
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Barden_G_12_CHEVRON_SR1_2_Catalog.pdf
