Baldor-Reliance CM3534 BALCM3534

Baldor-Reliance CM3534 Type 3413M Continuous Duty AC Motor, 0.33 hp, 208/230/460 VAC, 60 Hz, 3 Phase, 56C Frame, 1725 rpm Speed, C-Face/Rigid Base Mounting

  • Manufacturer: ABB Baldor-Reliance
  • Brand Name: Baldor-Reliance
  • Part Number: BALCM3534
  • MPN: CM3534
  • UPC: 781568110102
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

Baldor-Reliance, CM3534, AC Motor, Type 3413M Continuous Duty, General Purpose AC Motors, Compressor Motors, Fan and Blower Motors Application, 0.33 hp, 208/230/460 VAC, 1.9/1.6/0.8 A, 60 Hz Frequency, 3 ph, 1725 rpm Speed, 1 Speed, 56C Frame, 5/8 in Shaft, Reversible Rotation, 1.35 Service Factor, 4.7 ft-lb Torque, C-Face/Rigid Base Mounting, 40 to 76 deg C, Steel, 11.35 in L x 9.28 in W Dimensions

Amperage Rating      :      1.9/1.6/0.8 A
Application Type      :      General Purpose AC Motors, Compressor Motors, Fan and Blower Motors
Bearing Type      :      Ball
Dimensions      :      11.35 in L x 9.28 in W
Enclosure Type      :      TEFC/NEMA B
Frame      :      56C
Frequency Rating      :      60 Hz
Horsepower      :      0.33 hp
Insulation Class      :      Class F
Material      :      Steel
Mounting Type      :      C-Face/Rigid Base
Number of Speeds      :      1
Phase      :      3
Rotation      :      Reversible
Service Factor      :      1.35
Shaft Size      :      5/8 in
Special Features      :      Continuous Duty Motor
Speed      :      1725 rpm
Temperature Rating      :      40 to 76 deg C
Torque Rating      :      4.7 ft-lb
Type      :      Type 3413M Continuous Duty
  • Locked DE bearing to allow mounting in any configuration
  • 60 Hz designs with 50 Hz information on 2, 4, 6-pole 1 to 125 hp ratings
  • Suitable for inverter use per NEMA MG1 part 31.4.4.2
  • Simple F1 to F2 conversion on cast iron frames
  • Designed for longevity with ok 3 years warranty on premium efficient Super-E® motors
  • Pressure cast aluminum endplates with ribbed design for rigidity
  • Locked drive end bearing
  • Heavy gauge steel frames
  • Super-E® motors have NEMA Premium® efficiency
  • Without drip cover
  • Without auxiliary box
