American Cylinder 1500DVS-6.00-2-4 ACY1500DVS-6.00-2-4
Pivot mount bracket for compatible American Cylinder units. Supports pin-style mounting for angular movement.
- Manufacturer: American Cylinder Co., Inc.
- Brand Name: American Cylinder
- Part Number: ACY1500DVS-6.00-2-4
- MPN: 1500DVS-6.00-2-4
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
1500DVS-X.XX (1-1/2" Bore)AIR CYL;UNIV. MNT;SS BODY CYL. [1.50X6.00]Description1-1/2" BORE DOUBLE ACTING AIR CYLINDER - STAINLESS STEEL SERIES - UNIVERSAL MOUNT- 3/4-16 MOUNTING THREADS- 0.37" DIAMETER PIVOT PIN- 7/6-20 ROD THREADS STANDARD- 1/8 NPT PORTSNote: (-8) option changes rod diameter to 1/2", mounting thread to 1"-14, and ports to 1/4 NPT
The American Cylinder 1500DVS-6.00-2-4 pivot mount bracket supports pin-style mounting for compatible cylinders. Ideal for applications where the cylinder needs to pivot slightly during stroke travel. Estimated weight: ~1.1 lb.
- Manufacturer: American Cylinder
- Manufacturer Part #: 1500DVS-6.00-2-4
