G & G Manufacturing 001050265 GGM001050265
G&G 001050265 is a 5026X weld-on roller chain sprocket for #50 chain with 26 teeth and 0.625 in pitch. Designed for use with an X Series WELDAHUB.
- Manufacturer: G & G MANUFACTURING CO.
- Brand Name: G & G Manufacturing
- Part Number: GGM001050265
- MPN: 001050265
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Versatile G&G 5026X weld-on sprocket for #50 roller chain. The WELDASPROCKET design pairs with X Series WELDAHUBS for flexible shaft-bore and replacement configurations.
G&G Manufacturing 001050265 is a NOVA Import 5026X WELDASPROCKET designed for #50 single-pitch roller chain. The sprocket has 26 teeth and 0.625 in chain pitch, and the X suffix identifies compatibility with G&G X Series WELDAHUBS. The weld-on design allows the sprocket to be combined with the appropriate hub and bore configuration for repair, replacement and custom power-transmission applications.
| Bore Diameter | : | Number of Teeth 26 |
| Chain Size | : | 50 |
| Material | : | Steel |
| Number of Teeth | : | 26 |
| Outside Diameter | : | 5.52 in |
| Pitch Diameter | : | 5.185 in |
| Pitch | : | 0.625 in |
| Series | : | WELDASPROCKET |
| Type | : | Weld-On Sprocket |
- G&G 5026X WELDASPROCKET
- Designed for #50 roller chain
- 26 teeth
- 0.625 in chain pitch
- X Series WELDAHUB compatibility
- Weld-on sprocket design
- NOVA Import product
- Suitable for repair, replacement and custom drive applications
