AMI Bearings UCX11-35 AMIUCX11-35
UCX11-35 is a medium-duty spherical-OD insert for 2-3/16" shafts, offering higher load capacity and improved misalignment tolerance in compatible housings.
- Manufacturer: AMI Bearings
- Brand Name: AMI Bearings
- Part Number: AMIUCX11-35
- MPN: UCX11-35
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
UCX11-35 is a strong choice when you need more capacity than a standard insert but still want easy service and common mounting. Its spherical OD helps it seat properly in matched housings, supporting better alignment under real operating conditions.Core fit dimensions include a 2-3/16 in bore, 4.3307 in insert OD, and a 2.563 in inner ring width, making interchange verification straightforward.
| Bearing Material | : | AISI 52100 Steel |
| Bore Diameter | : | 35 mm |
| Finish | : | Standard |
| Load Capacity | : | Dynamic 43000 / Static 29000 N |
| Outside Diameter | : | 85 mm |
| Series | : | UCX00 |
| Temperature Rating | : | 0 to 212 deg F |
- Type: medium-duty set screw locking bearing insert (spherical OD)
- Shaft bore (Bore Size): 2-3/16 in
- Outside diameter (Insert OD): 4.3307 in
- Inner ring width: 2.563 in
- Outer ring width: 1.024 in
- Chamfer/fillet radius: 0.098 in
- Set screw thread: 3/8-24
- Dynamic load rating: 11800 lbf; Static load rating: 8120 lbf
- Weight: 3.79 lb
