AMI Bearings UCP X15-47 AMIUCPX15-47
UCPX15-47 is a robust pillow block unit for 2-15/16" shafts, designed for larger shaft support with a strong base-mount footprint.
- Manufacturer: AMI Bearings
- Brand Name: AMI Bearings
- Part Number: AMIUCPX15-47
- MPN: UCP X15-47
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
UCP X15-47 is built for larger shafts and heavier loads where you need a pillow block that stays rigid and runs reliably. It is a strong fit for industrial equipment, processing lines, and high-load shafting where stability is everything.The catalog dimensions include a mounting slot range for easier alignment, along with a defined base and height profile to support confident installation and replacement planning.
| Base Width | : | 6-31/32 in |
| Bolt Center-to-Center Length | : | 7-7/8–10-1/8 in |
| Bore Diameter | : | 2-15/16 in |
| Compatible Bearing Type | : | UCX15-47 |
| Locking Device | : | Set Screw |
| Material | : | Cast Iron Housing |
| Mounting Type | : | Pillow Block |
| Overall Height | : | 3-1/2 in |
| Overall Length | : | 13 in |
| Overall Width | : | 3-1/2 in |
| Series | : | UCPX00 |
- Type: heavy pillow block mounted bearing unit (set screw locking)
- Shaft bore (Bore Size): 2-15/16 in
- Bolt size: 7/8 in
- Lubrication fitting tap: 1/8-27 NPT
- Weight: 25.13 lb
- Shaft center height from base: 3-1/2 in
- Overall base length: 13 in
- Mounting slot spacing (min/max): 7-7/8 in / 10-1/8 in
- Mounting hole diameter: 1-5/16 in
- Overall housing width: 6-31/32 in
