AMI Bearings UCP-206 AMIUCP206
UCP206 is a cast pillow block unit for 30 mm shafts, delivering stable base mounting with easy service access and standard lubrication.
- Manufacturer: AMI Bearings
- Brand Name: AMI Bearings
- Part Number: AMIUCP206
- MPN: UCP-206
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
UCP-206 is a go-to pillow block style because it is simple, reliable, and easy to mount. It bolts down to a base, supports a 30 mm shaft, and provides a stable platform for conveyors, fans, augers, and general industrial rotating assemblies.The base mounting and slot spacing range make it installer-friendly during alignment, while standard lubrication provisions support routine maintenance.
| Base Width | : | 83 mm |
| Bolt Center-to-Center Length | : | 113–129 mm |
| Bore Diameter | : | 30 mm |
| Compatible Bearing Type | : | UC206 |
| Locking Device | : | Set Screw |
| Material | : | Cast Iron Housing |
| Mounting Type | : | Pillow Block |
| Overall Height | : | 42.9 mm |
| Overall Length | : | 165 mm |
| Overall Width | : | 48 mm |
| Series | : | UCP200 |
- Type: pillow block mounted bearing unit (set screw locking)
- Shaft bore (Bore Size): 30 mm
- Bolt size: M14
- Lubrication fitting tap: 1/8-27 NPT
- Weight: 2.90 lb
- Shaft center height from base: 42.9 mm
- Overall base length: 165 mm
- Mounting slot spacing (min/max): 113 mm / 129 mm
- Mounting hole diameter: 18 mm
- Overall housing width: 83 mm
