AMI Bearings UCLF201-8 AMIUCLF201-8
UCLF201-8 is a compact 4-bolt flange unit for 1/2" shafts, ideal for light-duty equipment needing easy alignment and serviceability.
- Manufacturer: AMI Bearings
- Brand Name: AMI Bearings
- Part Number: AMIUCLF201-8
- MPN: UCLF201-8
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
UCLF201-8 delivers a reliable flange-mount bearing solution in a compact package. It is a great fit for small conveyors, light machinery, guards, and auxiliary rollers where you want stable support and quick replacement without overbuilding the assembly.It supports a 1/2 in bore and uses a compact 4-bolt flange footprint for easy integration into small frames and plates.
| Bearing Material | : | AISI 52100 Steel |
| Bolt Center-to-Center Length | : | 2-1/8 in |
| Bore Diameter | : | 1/2 in |
| Locking Device | : | Set Screw |
| Overall Depth | : | 1-3/32 in |
| Overall Height | : | 1.287 in |
| Overall Length/Diameter | : | 3 in |
| Series | : | UCLF200/UCF200 |
- Type: compact 4-bolt flange mounted bearing unit (set screw locking)
- Shaft bore (Bore Size): 1/2 in
- Bolt size: 3/8 in
- Lubrication fitting tap: 1/4-28 UNF
- Weight: 1.15 lb
- Mounting hole center-to-center: 3 in
- Overall flange width: 2-1/8 in
- Mounting hole diameter: 3/8 in
- Housing projection/depth: 1-3/32 in
- Overall unit height: 1.287 in
