AMI Bearings UCFT210-30 AMIUCFT210-30
UCFT210-30 is a heavier 2-bolt flange unit for 1-7/8" shafts, built for stable mounting and reliable service access.
- Manufacturer: AMI Bearings
- Brand Name: AMI Bearings
- Part Number: AMIUCFT210-30
- MPN: UCFT210-30
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
UCFT210-30 is a strong choice when you want 2-bolt flange convenience on a larger shaft. It is well suited for industrial machinery where mounting space is limited but you still need stable support and service-friendly access.With a 1-7/8 in bore and clearly defined bolt spacing and envelope dimensions, it is easy to spec into equipment or swap during rebuilds.
| Bearing Material | : | AISI 52100 Steel |
| Bolt Center-to-Center Length | : | 6-3/16 in |
| Bore Diameter | : | 1-7/8 in |
| Locking Device | : | Set Screw |
| Overall Depth | : | 1-9/16 in |
| Overall Height | : | 2.158 in |
| Overall Length/Diameter | : | 7-7/16 in |
| Series | : | UCFT200 |
- Type: 2-bolt flange mounted bearing unit (set screw locking)
- Shaft bore (Bore Size): 1-7/8 in
- Bolt size: 9/16 in
- Lubrication fitting tap: 1/8-27 NPT
- Weight: 4.63 lb
- Mounting hole center-to-center: 7-7/16 in
- Overall flange width: 6-3/16 in
- Mounting hole diameter: 9/16 in
- Housing projection/depth: 1-9/16 in
- Overall unit height: 2.158 in
