AMI Bearings UCFT208-25 AMIUCFT208-25

UCFT208-25 is a 2-bolt flange unit for 1-9/16" shafts, providing stable mounting and easy service in compact frame layouts.

  • Manufacturer: AMI Bearings
  • Brand Name: AMI Bearings
  • Part Number: AMIUCFT208-25
  • MPN: UCFT208-25
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at EVANSVILLE, IN
  • loading Check Availability at All Branches

UCFT208-25 is a practical 2-bolt flange solution for conveyors and general machinery where space and simplicity matter. Set screw locking keeps installation fast, while the flange form factor makes mounting easy on plates and panels.It supports a 1-9/16 in bore and includes clear bolt pattern and envelope dimensions for straightforward layout and replacement.

Bearing Material      :      AISI 52100 Steel
Bolt Center-to-Center Length      :      5-21/32 in
Bore Diameter      :      1-9/16 in
Locking Device      :      Set Screw
Overall Depth      :      1-1/2 in
Overall Height      :      2.017 in
Overall Length/Diameter      :      6-3/4 in
Series      :      UCFT200
  • Type: 2-bolt flange mounted bearing unit (set screw locking)
  • Shaft bore (Bore Size): 1-9/16 in
  • Bolt size: 1/2 in
  • Lubrication fitting tap: 1/8-27 NPT
  • Weight: 3.97 lb
  • Mounting hole center-to-center: 6-3/4 in
  • Overall flange width: 5-21/32 in
  • Mounting hole diameter: 9/16 in
  • Housing projection/depth: 1-1/2 in
  • Overall unit height: 2.017 in
