AMI Bearings UCFC214 AMIUCFC214
  1. pin-int

AMI Bearings UCFC214 AMIUCFC214

UCFC214 is a heavy, piloted flange cartridge unit for 70 mm shafts, ideal for robust piloted mounting and high-capacity service.

  • Manufacturer: AMI Bearings
  • Brand Name: AMI Bearings
  • Part Number: AMIUCFC214
  • MPN: UCFC214
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

UCFC214 brings piloted mounting benefits to larger shafts and heavier equipment. The cartridge-style housing helps locate the unit accurately in a mating bore, supporting more consistent alignment and repeatable replacements.With a 70 mm bore and M16 mounting bolts, it is a strong fit for heavy conveyors, processing machinery, and industrial equipment where stability and serviceability both matter.

Bore Diameter      :      70 mm
Series      :      UCFC200
  • Type: piloted flange cartridge unit (set screw locking)
  • Shaft bore (Bore Size): 70 mm
  • Bolt size: M16
  • Lubrication fitting tap: 1/8-27 NPT
  • Weight: 15.2 lb
  • Overall mounting length: 215 mm
  • Bolt-hole center spacing: 177 mm
  • Pilot diameter: 40 mm
  • Overall unit projection: 61.4 mm
