AMI Bearings UCFC206 AMIUCFC206
UCFC206 is a piloted flange cartridge unit for 30 mm shafts, designed for clean piloted mounting and confident shaft retention with set screws.
- Manufacturer: AMI Bearings
- Brand Name: AMI Bearings
- Part Number: AMIUCFC206
- MPN: UCFC206
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
UCFC206 is a great choice when you want the added location control of a piloted mount. The piloted flange cartridge style helps improve repeatability during installation and replacement, making it well suited for OEM equipment and fabricated housings.This unit supports a 30 mm bore, uses M10 mounting bolts, and provides the core layout dimensions needed for plate prep and interchange.
| Bore Diameter | : | 30 mm |
| Locking Device | : | Set Screw (UC200 series typical) |
| Series | : | UCFC200 |
- Type: piloted flange cartridge unit (set screw locking)
- Shaft bore (Bore Size): 30 mm
- Bolt size: M10
- Lubrication fitting tap: 1/8-27 NPT
- Weight: 3.35 lb
- Overall mounting length: 125 mm
- Bolt-hole center spacing: 100 mm
- Pilot diameter: 23 mm
- Overall unit projection: 32.2 mm
