AMI Bearings UCF206 AMIUCF206
UCF206 is a cast 4-bolt flange unit for 30 mm shafts, combining a UC206 insert with a sturdy flange housing for stable, serviceable mounting.
- Manufacturer: AMI Bearings
- Brand Name: AMI Bearings
- Part Number: AMIUCF206
- MPN: UCF206
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
UCF206 is a classic mounted-bearing solution for plate and frame mounting. The 4-bolt flange footprint provides stable support, while set screw locking makes installation and replacement quick for maintenance teams.Designed around a 30 mm bore and M10 mounting bolts, it is well suited for conveyors, rotating shafts, and general industrial machinery where reliability and interchange matter.
| Bearing Material | : | AISI 52100 Steel (UC200 series) |
| Bore Diameter | : | 30 mm |
| Locking Device | : | Set Screw |
| Series | : | UCLF200/UCF200 |
- Type: cast 4-bolt flange mounted bearing unit (set screw locking)
- Shaft bore (Bore Size): 30 mm
- Bolt size: M10
- Lubrication fitting tap: 1/8-27 NPT
- Weight: 2.45 lb
- Mounting hole center-to-center: 108 mm
- Overall flange width: 83 mm
- Mounting hole diameter: 14 mm
- Housing projection/depth: 31 mm
- Overall unit height: 40.2 mm
