AMI Bearings MBLF2-10W AMIMBLF2-10W
MBLF2-10W is a compact, corrosion-resistant 2-bolt flange unit for 5/8" shafts, featuring a white thermoplastic housing and stainless insert for washdown-friendly environments.
- Manufacturer: AMI Bearings
- Brand Name: AMI Bearings
- Part Number: AMIMBLF2-10W
- MPN: MBLF2-10W
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
MBLF2-10W is a smart upgrade when corrosion, frequent washdown, or humidity shortens the life of traditional cast housings. Its white PBT thermoplastic housing and 440C stainless insert make it a strong fit for packaging, food-adjacent equipment, light-duty conveyors, and other environments where rust prevention matters.The narrow-width 2-bolt flange footprint is easy to mount in tight spaces, and the unit is designed for straightforward installation on a 5/8 in shaft using 1/4 in mounting bolts.
| Bearing Material | : | 440C Stainless Steel |
| Bore Diameter | : | 5/8 in |
| Locking Device | : | Set Screw |
| Overall Height | : | 1 in |
| Series | : | MBLF |
- Type: narrow-width 2-bolt flange unit (corrosion-resistant)
- Shaft bore (Bore Size): 5/8 in
- Bolt size: 1/4 in
- Housing material: PBT thermoplastic; housing color: White
- Insert material: 440C stainless steel
- Lubrication fitting tap: 1/4-28 UNF
- Mounting hole center-to-center: 3-3/16 in
- Overall flange width: 2-1/2 in
- Mounting hole diameter: 25/64 in
- Weight: 0.26 lb
